HP EliteDisplay E240 User Manual

Assigning the Function buttons
Pressing one of the four front bezel Function buttons activates the buttons and displays the icons above the
buttons. The factory default button icons and functions are shown below.
Button Function
1 Menu Opens the OSD (On-Screen Display) menu.
2Information
(Function button 1 -
assignable)
Opens the Information menu.
3 Next Active Input
(Function button 2 -
assignable)
Switches the monitor's input source to the next active input.
4Brightness
(Function button 3 -
assignable)
Opens the Brightness adjustment scale.
You can change the Function buttons from their default values so that when the buttons are activated you
can quickly access commonly used menu items.
To assign the Function buttons:
1. Press one of the four front bezel buttons to activate the buttons, and then press the Menu button to
open the OSD.
2. In the OSD menu, select Menu Control > Assign Buttons and then select one of the available options for
the button you want to assign.
NOTE: You can only assign the three Function buttons. You can not reassign the Menu button or the Power
button.
18 Chapter 2 Using the monitor

HP EliteDisplay E240 Specifications

General

3D	No
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LED
Viewable size, vertical	296.46 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1400 x 900, 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switch	Yes
USB hub version	2.0
USB Type-A downstream ports quantity	3
Product color	Black
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	35 W
Power consumption (off)	0.12 W
Annual energy consumption	31 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W

Weight and Dimensions

Depth (without stand)	49.5 mm
Width (without stand)	557.2 mm
Height (without stand)	342.2 mm
Weight (without stand)	3800 g
