Environmental Requirements Temperature
Operating Temperature
Storage Temperature
5 to 35° C
-20 to 60° C
41 to 95° F
-4 to 140° F
Power Source 100–240 VAC 50/60 Hz
Input Terminal One HDMI connector, one DisplayPort
connector, one VGA connector
61 cm/24–inch model
Display
Type
61 cm wide screen
TFT-LCD
24-inch wide screen
Viewable Image Size 61 cm diagonal 24-inch diagonal
Maximum Weight (Unpacked) 5.97 kg 13.16 lbs
Dimensions (include base)
Height (highest position)
Height (lowest position)
Depth
Width
51.90 cm
39.37 cm
18.90 cm
56.22 cm
20.43 inches
15.50 inches
7.44 inches
22.13 inches
Maximum Graphic Resolution 1920 x 1200
Optimum Graphic Resolution 1920 x 1200
Environmental Requirements Temperature
Operating Temperature
Storage Temperature
5 to 35° C
-20 to 60° C
41 to 95° F
-4 to 140° F
Power Source 100–240 VAC 50/60 Hz
Input Terminal One HDMI connector, one DisplayPort
connector, one VGA connector
68.47 cm/27–inch QHD model
Display
Type
68.47 cm wide screen
TFT-LCD
27-inch wide screen
Viewable Image Size 68.47 cm diagonal 27-inch diagonal
Maximum Weight (Unpacked) 6.14 kg 13.54 lbs
Dimensions (include base)
Height (highest position)
Height (lowest position)
55.786 cm
40.944 cm
22 inches
16.1 inches
61 cm/24–inch model 29

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteDisplay E240 and is the answer not in the manual?

HP EliteDisplay E240 Specifications

General IconGeneral
3DNo
Aspect ratio16:9
Screen shapeFlat
Display diagonal23.8 \
Display technologyLED
Viewable size, vertical296.46 mm
Contrast ratio (dynamic)5000000:1
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewable size, horizontal527.04 mm
Display brightness (typical)250 cd/m²
Supported graphics resolutions640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1400 x 900, 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switchYes
USB hub version2.0
USB Type-A downstream ports quantity3
Product colorBlack
Country of originChina
Market positioningBusiness
Pivot angle0 - 90 °
Tilt angle range-5 - 25 °
Panel mounting interface100 x 100 mm
Sustainability certificatesENERGY STAR
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)35 W
Power consumption (off)0.12 W
Annual energy consumption31 kWh
Power consumption (standby)0.5 W
Power consumption (typical)25 W
Weight and Dimensions IconWeight and Dimensions
Depth (without stand)49.5 mm
Width (without stand)557.2 mm
Height (without stand)342.2 mm
Weight (without stand)3800 g
