Item Description
Panel/trim kit, includes
(1) Left side trim
(2) Right side trim (includes ngerprint reader and cable)
(3) Top trim
(4) Bottom trim
(5) Rear port cover
(6) Rear cover (main)
(7) Center rear I/O panel with mylar
(8) Rear I/O port cover
(9) Front bezel (for use in non-touch models)
(10) Optical drive bezel trim (only for use in models with an expansion option in the optical drive bay)
(11) Rubber feet (right and left)
* Optical drive bezel blank (for use in models without an optical drive; not illustrated)
* Stands (not illustrated)
Adjustment Height Stand
Easel Stand
Recline Stand
* VESA cover (for use in models with out a stand)
* Display (touch screen; not illustrated)
* Display Kit (non-touch; not illustrated)
16 Chapter 2 Illustrated parts catalog
