HP EliteOne 705 G2 User Manual

8. Lift the module to a 45-degree angle, and then pull it away to remove it from the socket (3).
To install the WLAN module, reverse the removal procedures.
When connecting the antennas cables, connect the cable labeled “1” (black sticker) to the AUX “1” connector
on the module and the cable labeled “2” (white sticker) to the MAIN “2” connector on the module.
NOTE: WLAN modules are designed with a notch to prevent incorrect insertion.
WLAN module 57

HP EliteOne 705 G2 Specifications

General

Brand	HP
Model	EliteOne 705 G2
Category	Desktop
Language	English
