HP Engage Go Convertible System Hardware Reference Guide

Attaching an I/O connectivity base to the HP Engage Go
Convertible System
You can attach an I/O connectivity base to the bottom of the mobility system dock’s stability base.
1. Turn o the mobility system properly through the operating system, and turn o any external devices.
2. Disconnect the power cords from the mobility system and I/O connectivity base.
IMPORTANT: Regardless of the power-on state, voltage is always present on the system board as long
as the system is plugged into an active AC outlet. You must disconnect the power cord and wait
approximately 30 seconds for the power to drain to avoid damage to the internal components.
3. Remove the cover on the I/O connectivity base by removing the four screws on the underside of the I/O
connectivity base (1), and then lifting the cover o the I/O connectivity base (2).
4. Connect the USB Type-C power cable to the USB Type-C port on the underside of the dock’s column.
22 Chapter 3 Hardware congurations and upgrades
