ENWW The HP Jetdirect EIO Control Panel Menu 247
CFG TCP/IP= Selects whether you want to access the TCP/IP menu and set
TCP/IP protocol parameters.
NO (default): Bypass the TCP/IP menu items.
YES: Access the TCP/IP menu items.
● BOOTP=YES* enables configuration by a BootP Server.
● DHCP=YES* enables configuration by a DHCP Server.
If DHCP=YES* and the print server has a DHCP lease, you
can choose to configure the following DHCP settings:
■ RELEASE: Choose YES to release, or NO to save, the
current DHCP lease.
■ RENEW: Choose YES to renew the current DHCP lease,
or NO to not renew the DHCP lease.
● AUTO IP=YES* will automatically assign a link-local address
in the form 169.254.x.x.
If you specify BOOTP=NO*, DHCP=NO* and AUTO IP=NO*, you
can manually set the following TCP/IP parameters from the
control panel:
■ Each byte of the IP address (IP)
■ Subnet Mask (SM)
■ Syslog Server (LG)
■ Default Gateway (GW)
■ Idle Timeout period (default is 270 seconds, 0 disables the
timeout)
● CFG DNS 1=YES* will allow you to specify the IP address of
a primary DNS server, one byte at a time.
● CFG DNS 2=YES* will allow you to specify the IP address of
a secondary DNS server, one byte at a time.
Print a Jetdirect configuration page to verify your settings.
However, note that the print server may overwrite selected
parameters with values that ensure proper operation.
CFG IPX/SPX= Selects whether you want to access the IPX/SPX menu and set
IPX/SPX protocol parameters.
NO (default): Bypass the IPX/SPX menu items.
YES: Access the IPX/SPX menu items.
In the IPX/SPX menu, you can specify the Frame Type parameter
used on your network.
■ AUTO (default) will automatically set and limit the frame
type to the first one detected.
■ For Ethernet cards, frame type selections include
EN_8023, EN_II, EN_8022, EN_SNAP.
Table B.1 HP Jetdirect Classic Control Panel Menu (2 of 3)
Menu Item Description
