8. If it is necessary to replace the display inverter, release the inverter (1) as far as the display panel
cable and backlight cable allow.
9. Disconnect the display panel cable (2) and the backlight cable (3) from the display inverter.
10.
Remove the display inverter from the display enclosure. The display inverter is available using spare
part number 431391-001.
11.
If it is necessary to replace the display panel or the display hinges, remove the six Phillips PM2.5×5.0
screws (1) that secure the display panel to the display enclosure.
Component replacement procedures 59
