7
Screw listing
This section provides specification and reference information for the screws used in the computer. The
screws listed in this section are available in the Screw Kit, spare part number 462854-001, or the Display
Screw Kit, spare part number 461947-001.
Phillips PM3.0×4.0 screw
Color Quantity Length Thread Head diameter
Silver 4 4.0 mm 3.0 mm 5.0 mm
Where used: 4 screws that secure the hard drive bracket to the hard drive
Phillips PM3.0×4.0 screw 89
