17. Remove the wireless antenna transceivers (3) and cables (4) from the display enclosure. The wireless
antenna transceivers and cables are available using spare part number 449726-001.
18.
If it is necessary to replace the microphone cable, release the tabs built into the display enclosure
shielding (1) that secure the microphone cable.
19. Remove the microphone receiver (2) from the clip built into the display enclosure and the microphone
cable (3) from the display enclosure. The microphone is available in the Display Cable Kit, spare
part number 433287-001.
20.
If it is necessary to replace the camera module cable, release the tabs built into the display enclosure
shielding (1) that secure the camera module cable.
Component replacement procedures 61
