6–8 Maintenance and Service Guide
Specifications
072 - 073 Motherboard resources
080 - 080 Motherboard resources
081 - 08F Direct memory access controller
092- 092 Motherboard resources
0A0 - 0A1 Programmable interrupt controller
0B0 - 0B1 Motherboard resources
0C0 - 0DF Direct memory access controller
0F0 - 0FE Numeric data processor
380 - 387 Motherboard resources
3B0 - 3BB ATI Mobility Radeon HD 4300 series
3B0 - 3BB PCI standard PCI-to-PCI bridge
3C0 - 3DF ATI Mobility Radeon HD 4300 series
3C0 - 3DF PCI standard PCI-to-PCI bridge
400 - 4CF Motherboard resources
4D0 - 4D1 Motherboard resources
4D6 - 4D6 Motherboard resources
680 - 6FF Motherboard resources
77A - 77A Motherboard resources
C00 - C01 Motherboard resources
C14 - C14 Motherboard resources
C50 - C52 Motherboard resources
C6C - C6C Motherboard resources
C6F - CGF Motherboard resources
CD0 - CDB Motherboard resources
CD0 - CDB PCI bus
2000 - 20FF Realtek RTL8102/8103 Family PCI-E FE NIC
2000 - 2FFF PCI standard PCI-to-PCI bridge
3000 - 30FF ATI Mobility Radeon HD 4300 series
3000 -30FF PCI standard PCI-to-PCI bridge
4010 - 401F Standard AHCI 1.0 Serial ATA Controller
4030 - 4037 Standard AHCI 1.0 Serial ATA Controller
4038 - 403F Standard AHCI 1.0 Serial ATA Controller
4048 - 404B Standard AHCI 1.0 Serial ATA Controller
404C - 404F Standard AHCI 1.0 Serial ATA Controller
I/O address (hex) System function (shipping configuration)
