7–6 Maintenance and Service Guide
Screw listing
Phillips PM2.5×5.5 captive screws
Where used:
1 One captive screw (secured by a C-clip) that secures the wireless module compartment cover to the base
enclosure
2 Four captive screws (secured by C-clips) that secure the hard drive cover to the base enclosure
Color Quantity Length Thread Head diameter
Black 5 5.5 mm 2.5 mm 4.4 mm
