Screw listing
Maintenance and Service Guide 7–7
Phillips PM2.5×6.5 screws
Where used: 2 screws that secure the hard drive to the base enclosure
Where used:
1 One screw that secures the optical drive to the base enclosure
2 Five screws that secure the keyboard to the base enclosure
Color Quantity Length Thread Head diameter
Black 32 6.5 mm 2.5 mm 4.4 mm
