Optical drive
NOTE: The optical drive spare part kit includes an optical drive bezel and optical drive bracket.
Description Spare part number
DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe for use with:
●
Biscotti computer models 614549-001
●
Matte black computer models 616482-001
●
Charcoal computer models (for model 1.1 only) 620541-001
Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive for use with:
●
Biscotti computer models 614548-001
●
Matte black computer models 616480-001
●
Charcoal computer models (for model 1.1 only) 620540-001
Before removing the optical drive:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn on
the computer, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC
outlet and then disconnecting the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
5. Remove the wireless/memory module compartment cover (see
Memory module on page 50).
Remove the optical drive:
1. Position the computer upside down with the front toward you.
2. Remove the Phillips PM2.5x5.0 screw (1) that is identified by the optical disk icon.
3. Insert a thin tool, such as a screw driver (2), into the release access slot in the hard drive bay.
Component replacement procedures 45
