4. Lift the cover off the computer (3). The wireless/memory module compartment cover is included
in the plastics kit, spare part number 616497-001.
NOTE: Small tabs hold the cover in place. Firmly pull up on the cover to release the tabs.
5. Unplug the RTC battery from the system board (1).
6. Use a sharp, non-conductive, tool to release the RTC battery from the adhesive material that
secures the RTC battery to the system board..
7. Lift the battery (2) out of the computer.
Reverse this procedure to install the RTC battery.
52 Chapter 4 Removal and replacement procedures
