RS-232 Console Port Connector and Cable Pin-Outs
The hub’s console connector is wired as if it is a terminal (DTE), ready to be
connected to a modem (DCE). The HP AdvanceStack hubs include a null
modem cable that can be used to directly connect a PC to be used as the
console. To connect a modem to the hub, use a standard RS-232-C modem
cable.
This section provides pin assignment information for the cables you can use
on the hub’s RS-232 management console port.
Pin-Out for Hub’s RS-232 Port Connector
PIN US CCITT DIN
1DCD 109M5
2Rx 104D2
3Tx 103D1
4DTR 108S1
5GND 102-
6 DSR 107 M1
7RTS 105S2
8CTS 106M2
9RI 125M3
Cables and Connectors
Cables and Connectors
A-6
