HP J2415A - (For PC with 9-Pin Male Connector; 3-Wire Cable for Direct Console Connection; RS-232-C Null ModemCable (Supplied with the Hub for PC with 9-Pin Male Connector)

RS-232-C “Null Modem”Cable
(supplied with the hub)
(for PC with 9-Pin Male Connector)
PC end
9-pin female
Hub end
9-pin female
1 1 DCD
22Rx
33Tx
44DTR
5 5 GND
6 6 DSR
7 7 RTS
8 8 CTS
99RI
3-Wire Cable for Direct Console Connection
PC end
9-pin female
Hub end
9-pin female
22Rx
33Tx
55GND
Cables and Connectors
Cables and Connectors
A-7
