Physical
HP J2415A 100VG Hub-14
Width:
44.2 cm (17.4 in)
Depth:
32.3 cm (12.7 in)
Height:
6.6 cm (2.6 in)
Weight:
4.3 kg (9.5 lb)
Electrical
(The HP AdvanceStack 100VG Hub-14 automatically adjusts to any voltage between 100-127
and 200-240 volts and either 50 or 60 Hz.)
ac voltage:
100-127 volts 200-240 volts
Maximum current:
0.90 A max 0.60 A max
Frequency range:
50/60 Hz 50/ 60 Hz
Environmental
Operating Non-Operating
Temperature:
+0°C to +55°C
(32°F to 131°F)
-40°C to 70°C
(-40°F to 158°F)
Relative humidity:
(non-condensing)
15% to 95%
at 40°C (104°F)
90%
at 65°C (149°F)
Maximum altitude:
4.6 km (15,000 ft) 4.6 km (15,000 ft)
Connectors
The RJ-45 twisted-pair ports are compatible with the IEEE 802.12
100VG-AnyLAN standard.
The RS-232-C console port conforms to V.22 bis.
Safety
Complies with
IEC 950: (1991)+A1,A2/.EN60950 I(1992)+A1,A2
UL1950
CSA 950
NOM-019-SCFI-1993
Specifications
