4-13
Web and MAC Authentication
Setup Procedure for Web/MAC Authentication
To display the current configuration of 802.1X, Web-based, and MAC
authentication on all switch ports, enter the show port-access config
command.
Figure 4-4. Example of show port-access config Command Output
3. Determine whether any VLAN assignments are needed for authenticated
clients.
a. If you configure the RADIUS server to assign a VLAN for an authen-
ticated client, this assignment overrides any VLAN assignments con-
figured on the switch while the authenticated client session remains
active. Note that the VLAN must be statically configured on the
switch.
b. If there is no RADIUS-assigned VLAN, the port can join an “Authorized
VLAN” for the duration of the client session, if you choose to configure
one. This must be a port-based, statically configured VLAN on the
switch.
c. If there is neither a RADIUS-assigned VLAN or an “Authorized VLAN”
for an authenticated client session on a port, then the port’s VLAN
membership remains unchanged during authenticated client ses-
sions. In this case, configure the port for the VLAN in which you want
it to operate during client sessions.
HP Switch (config)# show port-access config
Port Access Status Summary
Port-access authenticator activated [No] : Yes
Allow RADIUS-assigned dynamic (GVRP) VLANs [No] : Yes
Supplicant Authenticator Web Auth Mac Auth
Port Enabled Enabled Enabled Enabled
---- ---------- ------------- -------- --------
1 Yes No No Yes
2 No Yes No Yes
3 No Yes No No
4 No No No No
5 No No No No
6 No No No No
7 No No No No
8 No No No No
9 No No No No
10 No No No No
11 No No No No
12 No No No No
...
