35
JH298A
Figure 39 Front panel LEDs
(1) GE port yellow LED (2) GE port green LED (3) System status LED (SYS)
(4) VPN status LED (5) Micro SD card LED (6) LTE LED
(7) 2.4G WLAN LED (8) SFP port LED
JH299A
Figure 40 Front panel LEDs
(1) GE port yellow LED (2) GE port green LED (3) System status LED (SYS)
(4) VPN LED (5) Micro SD card LED (6) LTE LED
(7) 2.4G WLAN LED (8) SFP port LED
