9
System Board Connectors and Switches
System Board Connectors and Switches
Internal speaker
AUX
CD
Audio Front Panel
Microphone
Multimedia Front Panel Connector
(Headphone Out and Volume Control)
16-bit SCSI
Processor 1
Processor 2
AGP Slot
PCI Slots
RAIDport
IDE Connector
8-bit SCSI
Fan
Status Panel
Power
Fan
Switches
FDD
External
Battery
VRM 1 VRM 2
External Start
Memory Modules
ISA Slots
Fan
(airflow guide)
Video Board
LAN Board
