16
1 System Overview
Specifications and Characteristics
Specifications and Characteristics
Physical Characteristics
Electrical Specifications
System Processing Unit
Weight (excl. keyboard and display): 14.4 kilograms (31.68 pounds)
Dimensions: 47.0 cm max. (D) by 21,0 cm (W) by 49.0 cm (H)
(18.50 inches by 8.26 inches by 19.29 inches)
Footprint: 0.09 m
2
(1.06 sq ft)
Parameter Total Rating
Peak
(15
secs.)
Maximum per
PCI Slots
1
(1,2 & 5)
32-bit 33 MHz
Maximum per
PCI Slots
1
(3 & 4)
64-bit 66 MHz
Maximum for
Universal
AGP Pro Slot
2
Input voltage -
Switch select
100 - 127
VAC
200 -
250 V Vac
—— — —
Input current (max) 9 A 4.5 A — — — —
Input frequency 50 to 60 Hz — — — —
Available power 300 W 320 W 100 W for PCI slots and AGP Pro slot
Max current at +12 V 13.5 A 15 A 0.5 A 0.5 A 9.2 A
Max current at -12 V 0.8 A — 0.1 A 0.1 A —
Max current at +3.3 V 1.5 A — 7.6 A 7.6 A Imax(Vcc) = 7.6 A
Max current at Vddq
(3.3 V or 1.5 V)
— — — — Imax(Vddq) = 2 A
Max current at +5 V 32 A — 5 A 5 A 2 A
Max current at -5 V 0.5 A — — — —
Max current at +5Vstdby
3
combined with 3.3 V stdby
2 A — 1.5 A total on 3.3 V stdby
1.
The maximum power dissipation for a PCI card is 25 W (refer to PCI specifications 2.2 on page 31).
2.
An AGP Pro card uses the electrical and cooling resources of both the Universal AGP Pro slot and the adjacent PCI slot. Power
limitation is managed in the BIOS.
3.
Refer to System Board Switch 10 on page 33.
