HP LaserJet M1120 - Multifunction Printer - Page 91

3. Release the bottom tab (callout 3).
Figure 5-39 Remove the side covers (3 of 4)
3
4. Slightly rotate the back side of the right cover away from the product, and then slide it toward the
front of the product to release it.
Figure 5-40 Remove the side covers (4 of 4)
2
1
ENWW Product base 75
