4. Remove four screws from the formatter PCA (callout 3). Remove three screws (callout 4) from the
fax card. Remove the formatter and the fax card PCAs.
Figure 6-84 Removing the formatter (3 of 4)
4
3
5. Gently separate the formatter from the sheet-metal shield. Mount the replacement formatter on this
shield.
Figure 6-85 Removing the formatter (4 of 4)
