Locations of major components
Figure 2-3 Locations of major components; HP LaserJet Professional M1130 MFP series
6
3
5
4
1
2
7
8
1 Scanner lid
2 Scanner assembly
3 Output bin with extension for long paper
4 Print-cartridge door lift-tab
5 Paper-pickup tray
6 Short-media extender tool (paper stopper)
7 Power button
8 Control panel
112 Chapter 2 Solve problems ENWW
