Printer dimensions
Figure 1-1 Dimensions for the base printer
1
2
2
3
3
1
Printer fully closed Printer fully opened
1. Height 289 mm (11.4 in) 289 mm (11.4 in)
2. Depth Tray 2 dust cover closed: 376 mm (14.8 in)
Tray 2 dust cover open: 444 mm (17.5 in)
569 mm (22.4 in)
3. Width 410 mm (16.1 in) 410 mm (16.1 in)
Weight 11.6 kg (25.6 lb)
Figure 1-2 Dimensions for the printer with the 1 x 550-sheet paper feeder
1
1
2
2
3
3
Printer and accessories fully closed Printer and accessories fully opened
1. Height 419 mm (16.5 in) 419 mm (16.5 in)
2. Depth Tray 2 dust cover closed: 376 mm (14.8 in)
Tray 2 dust cover open: 444 mm (17.5 in)
569 mm (22.4 in)
ENWW Printer specifications 9
