Load paper to Tray 1 (multipurpose tray)
Introduction
The following information describes how to load paper in Tray 1. This tray holds up to 100 sheets of 75 g/m
2
(20 lb) paper.
NOTE: Select the correct paper type in the print driver before printing.
CAUTION: To avoid jams, never add or remove paper from Tray 1 during printing.
1. Grasp the handle on either side of Tray 1, and pull
it forward to open it.
2. Pull out the tray extension to support the paper.
3. Spread the paper guides to the correct size, and
then load paper in the tray. For information about
how to orient the paper, see
Tray 1 paper
orientation on page 15.
Make sure that the paper fits under the fill line on
the paper guides.
NOTE: The maximum stack height is 10 mm
(0.4 in), or approximately 100 sheets of 75g
paper.
4. Adjust the side guides so that they lightly touch
the paper stack, but do not bend it.
14 Chapter 2 Paper trays ENWW
