b. Place two of the alignment-bar extenders at the edges of the alignment bar.
c. Place two more alignment-bar extenders between each pair of edge holders that are going to be
used.
IMPORTANT: Do not place the extenders over the large holes in the alignment bar.
If an edge holder is at the edge of the alignment bar, then you do not need to place an extender at this
edge.
If the edge holders are placed at the edges of the substrate-advance belt due to the size of the substrate,
install only two alignment-bar extenders as shown below.
14 Chapter 2 Using the substrate edge holders with rigid substrates ENWW

HP Latex R1000 Specifications

General

Ink Types	HP Latex Inks
Print Technology	Latex
Print Resolution	1200 x 1200 dpi
Media Handling	Roll-to-roll
Applications	Signage, banners
Ink Colors	Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta
Part Number	CZ103A (Cyan), CZ104A (Magenta), CZ105A (Yellow), CZ106A (Black), CZ107A (Light Cyan), CZ108A (Light Magenta), CZ109A (White), CZ110A (Primer)
