Identifying display components
The major components of the display and their functions are shown here.
Figure 3-1 Display components
1
1
37
654
2
2
3
Table 3-1 Major components
Component Function
1 Speaker installation: 4 holes
2 Stand installation: 4 holes
3 Handles: 4
4 Control panel with power and OSD navigation buttons
5 Power and data connectors
6 Remote control sensor and ambient light sensor
7 Security cable provision
ENWW Identifying display components 7
