Level 1 Menu Level 2 Menu Level 3 Menu Description
IR out Enable — Enable the external IR receiver and IR daisy-chain
support.
Disable — Disable the external IR receiver and IR daisy-chain
support.
The default setting is Disable.
Firmware Update Current Ver. — Shows the version number of firmware
currently running on the display.
Detected Ver. — Shows the version number of firmware
detected on a USB device plugged into the display.
Yes/No — Choose yes to upgrade firmware on this display.
Color
Calibration
Color Calibration Enter — Enter the color calibration process.
Exit — Exit without calibrating color.
See
Tuning color on page 47 for details of the color
calibration process.
Result When calibration is complete, the display measures the
following parameters with the new correction:
Luminance
Color Temperature
Gamma
R, G, and B coordinates in CIE X,Y color space
The number of hours since calibration is also shown. If the
display has never been calibrated, that fact is shown.
Tile Mode
H Monitors Enter the number of displays in a row of your array.
The range is 1 — 5 and the default is 1.
V Monitors Enter the number of displays in a column of your array.
The range is 1 — 5 and the default is 1.
H Position Enter this display's column number, counting left to right.
The range is 1 — 5 and the default is 1.
V Position Enter this display's row number, counting top to bottom.
The range is 1 — 5 and the default is 1.
Natural Mode On — Image will overlap the bezel. The result is as though the
composite image was projected onto the video wall.
Off — Image will be contained in the viewing area. The result
is as though the composite picture was cut into separate
pieces laid close to each other.
See
Using Tile Mode on page 44 for more detail.
The default setting is Off.
Reset Returns all tile settings to their defaults.
ENWW Using the On-Screen Display menu 43
