- 18 -
4. TROUBLE IN DPM
TROUBLE IN DPM
TROUBLE IN U401
CHECK H/V SYNC LINE
NO
CHECK
U401 PIN 18,19,36,37
SYNC PULSE?
YES
5
U401-#18,36 H-SYNC
5
U401-#19,37 V-SYNC
Waveforms
5
