HP LP2065 Service Manual

- 22 -
DATE: 2006. 11. 20.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C202 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C203 JCE475EK638 KMG5.0TP50VB4.7M 4.7uF 20% 5
C204 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C205 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C206 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C207 JCE477EF638 KMG5.0TP16VB470M 470uF 20% 1
C208 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C209 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C210 JCE107EH638 KMG5.0TP25VB100M 100uF 20% 2
C213 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C214 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C218 JCE227BF638 KME5.0TP16VB220M 220uF 20% 1
C220 JCE107EF638 KMG5.0TP16VB100M 100uF 20% 1
C221 0CK105DK94A 0805F105Z500CT 1uF -20TO+80%
C223 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C224 JCE107EF638 KMG5.0TP16VB100M 100uF 20% 1
C226 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C227 JCE107EF638 KMG5.0TP16VB100M 100uF 20% 1
C228 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C229 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C236 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C250 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C251 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C252 JCE227BF638 KME5.0TP16VB220M 220uF 20% 1
C301 JCE107EH638 KMG5.0TP25VB100M 100uF 20% 2
C302 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C303 JCE107EF638 KMG5.0TP16VB100M 100uF 20% 1
C304 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C305 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C306 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C308 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C310 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C311 0CK105DK94A 0805F105Z500CT 1uF -20TO+80%
C313 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C314 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C316 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C318 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C320 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C321 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C322 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C323 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C324 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C325 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C326 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C327 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C328 0CK224CF56A 0603B224K160CT 220nF 10% 16V
C329 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C330 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C331 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C332 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C333 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C334 0CK103CK51A 0603B103K500CT 10nF 10% 50V
DATE: 2006. 11. 20.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C335 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C336 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C337 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C338 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C341 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C343 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C344 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C349 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C350 0CK224CF56A 0603B224K160CT 220nF 10% 16V
C351 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C352 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C353 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C354 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C355 0CK474CH94A 0603F474Z250CT 470nF -20TO+8
C356 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C357 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C358 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C359 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C360 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C361 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C362 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C363 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C364 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C365 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C366 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C367 0CK102CK56A 0603B102K500CT 1nF 10% 50V X
C368 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C369 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C370 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C371 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C372 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C373 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C375 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C376 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C377 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C380 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C381 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C401 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C402 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C403 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C404 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C405 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C406 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C407 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C408 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C409 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C410 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C411 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C412 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C414 0CC270CK41A C1608C0G1H270JT 27pF 5% 50V
C415 0CC270CK41A C1608C0G1H270JT 27pF 5% 50V
C416 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C417 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C418 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS

HP LP2065 Specifications

General

3D	Yes
Pixel pitch	0.255 x 0.255 mm
Response time	8 ms
Display diagonal	20.1 \
Display resolution	1600 x 1200 pixels
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 94 kHz
Contrast ratio (dynamic)	-
Contrast ratio (typical)	800:1
Display brightness (typical)	300 cd/m²
USB hub version	2.0
DVI-I ports quantity	2
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
LED indicators	Power
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	75 W
Storage temperature (T-T)	10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Certification	TCO'03, TUV-Ergo, UL, VCCI, CE, ISO 13406-2
Country of origin	China
Market positioning	Business

Weight and Dimensions

Depth (with stand)	220 mm
Height (with stand)	425 mm
Weight (with stand)	9200 g
Depth (without stand)	87 mm
Width (without stand)	443 mm
Height (without stand)	345 mm
Weight (without stand)	5750 g
