2. Remove the Quick Release from the pedestal base by removing the four screws.
Figure 3-12 Removing the HP Quick Release from the Pedestal Base
3. Mount the Quick Release to a swing arm or other mounting fixture using the four screws removed
from the Quick Release in the previous step.
Figure 3-13 Installing the Quick Release
CAUTION: The Quick Release can also be installed directly to a wall to mount the monitor panel.
It is designed to support a maximum of up to 10.9 kg (24 lbs). If you are mounting to a wall, HP
recommends that you consult with a qualified engineering, architectural, or construction
professional to determine the appropriate type and quantity of mounting fasteners required for your
application and to ensure that the mounting solution is properly installed to support applied loads.
Removing the Monitor Pedestal Base 17
