Front Panel Controls
Table 4-1 Monitor Front Panel Controls
Control Function
1 Function Performs the function set in the OSD menu (OSD Control >
Function Control).
2 Input Selects the video input (DVI-1, DVI-2, HDMI, DisplayPort,
Component, S-Video, or Composite).
3 + (Plus) Navigates forward through the OSD menu and increases
adjustment levels.
4 – (Minus)
●
Navigates backward through the OSD menu and
decreases adjustment levels.
●
When the OSD menu is inactive, activates the auto
adjustment feature to optimize the screen image.
5 Menu/Select Opens, selects or exits the OSD menu.
6 Power LED Green = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
7 Power Turns the monitor on or off.
22 Chapter 4 Operating the Monitor
