EL-MF877-00 Page 4

Template Revision C

Last revalidation date 09-September-2019

HPI instructions for this template are available at EL-MF877-01

4. Remove two acetate cloth tape and pull out the LED/30pin ffc cable .

5. Remove the rear support thirteen screws ,hinge four screws ,MB three screws

Dismantle the rear cover first from

the marked position

Remove 8PINFFC from the MB

Remove two screws
