Figure 1-2 Dimensions for printer with optional Tray 3
3
1
2
1
2
3
Printer fully closed Printer fully open
1. Height 531.8 mm (20.93 in) 788 mm (31.02 in)
2. Depth 472.3 mm (18.59 in) 1124.4 mm (44.27 in)
3. Width 415.4 mm (16.35 in) 415.4 mm (16.35 in)
Weight (with cartridges) 28.4 kg (62.61 lb)
Power consumption, electrical specifications, and acoustic emissions
See www.hp.com/support/colorljM377MFP for current information.
CAUTION: Power requirements are based on the country/region where the printer is sold. Do not convert
operating voltages. This will damage the printer and void the printer warranty.
Operating-environment range
Environment Recommended Allowed
Temperature 15° to 27°C (59° to 80.6°F) 15° to 30°C (59° to 86°F)
Relative humidity 20% to 70% relative humidity (RH), non-
condensing
10% to 80% RH, non-condensing
Altitude Not applicable 0 to 3048 m (0 to 10,000 ft)
ENWW Product specifications 11
