Hard drive
NOTE: Each hard drive spare part kit includes a cable adapter, bracket, and four rubber isolators.
Description Spare part
number
Hard drive:
250-GB, 5400-RPM 608763–001
320–GB, 5400–RPM 608764–001
Before removing a hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 38).
5. Remove the service cover (see
Battery on page 38).
Remove the hard drive:
1. Lift up the vinyl cover to expose the hard drive.
2. Using a small Phillips screwdriver, remove the 4 hard drive mounting screws.
Component replacement procedures
41
