Power connector cable
Description Spare part number
Power connector cable 622329-001
Power connector bracket 634873-001
Before removing the power connector cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the following components:
a. Battery (see
Battery on page 35).
b. Service access cover (see
Service access cover on page 38).
c. Hard drive (see
Hard drive on page 40).
d. Keyboard (see
Keyboard on page 50).
e. Top cover (see
Top cover on page 53).
f. Display assembly (see
Display assembly on page 56).
g. System board (see
System board on page 66).
Remove the power connector cable:
Component replacement procedures
69
