HP MINI 5103 User Manual

Replacing a hard drive
CAUTION: To prevent information loss or an unresponsive system:
Shut down the computer before removing the hard drive from the hard drive bay. Do not remove the
hard drive while the computer is on, in the Sleep state, or in Hibernation.
If you are not sure whether the computer is off or in Hibernation, turn the computer on by briefly pressing
the power button. Then shut down the computer through the operating system.
To remove a hard drive:
1. Save your work.
2. Shut down the computer and close the display.
3. Disconnect all external hardware devices connected to the computer.
4. Unplug the power cord from the AC outlet.
5. Turn the computer upside down on a flat surface.
6. Remove the battery from the computer.
7. Remove the 3 screws from the back edge of the computer.
8. Turn the computer display-side up, with the front toward you, and open the display.
90 Chapter 9 Drives

HP MINI 5103 Specifications

General

Graphics	Intel GMA 3150
Webcam	Integrated 2 MP webcam
Processor	Intel Atom N455 (1.66 GHz), Intel Atom N475 (1.83 GHz)
Display	10.1-inch diagonal LED-backlit HD (1366 x 768)
RAM	Up to 2 GB DDR3
Storage	160 GB HDD
Operating System	Windows 7 Starter
Battery	3-cell or 6-cell Lithium-Ion battery
Weight	2.64 lbs (1.2 kg)
Dimensions	10.3 x 7.1 x 0.9 inches
Wireless	802.11b/g/n
Ports	3 x USB 2.0, VGA
Card Reader	SD/MMC
Keyboard	95% full-size
