HP MSR 2000 Preparing For Installation

v
Figure 7 MSR4080 mounting brackets
Installing the router to the rack
CAUTION:
The mountin
g
brackets and rack shelf can support only the wei
g
ht of the router. Do not place any objec
t
on the router to avoid device damage.
To install the router to the rack:
1. Use a front mounting bracket to mark the positions of cage nuts, making sure they are at the same
level.
2. Insert one edge of a cage nut into the hole. Use a flat-blade screwdriver to compress the other edge
of the cage nut, and then push the cage nut fully into the hole.
3. Install other cage nuts to all the marked positions on the rack posts.

HP MSR 2000 Specifications

General

Brand	HP
Model	MSR 2000
Category	Network Router
Language	English
