HP MSR 2000 - AC Power Module; DC Power Module

v
 Install the PoE power module to PWR1 or PWR3. Before you install the PoE power module, remove
the filler panel from the slot.
 The PoE power module requires AC power input.
AC power module
Figure 60 AC power module
(1) Captive screw (2) Power switch
(3)
A
ir outlet vent (4) Power receptacle
DC power module
Figure 61 DC power module
(1) Captive screw (2) Power switch
(3) Air outlet vent (4) Power receptacle
1 2 3
4
