xi
3.
Use a Phillips screwdriver to fasten the grounding screws into the grounding screw holes.
4. Remove the grounding screw from the grounding point on the rack.
5. Attach the other end of the grounding cable to the grounding point on the rack, and secure it with
a screw.
Figure 13 Grounding the router through the grounding terminal on the rack
1
2
