HP MSR 2000 - Appendix C Slot Arrangement

1
Appendix C Slot arrangement
Each of the MSR3000 routers provides slots for SIC and HMIM interface cards. On the MSR3024,
MSR3044, and MSR3064, you can combine two SIC slots into one DSIC slot by removing the slot
divider.
The fixed ports on the MSR3000 panel are located in slot 0.
Table 9 Slot arrangement on the MSR3000 routers
Model Slot arran
g
ement
MSR301
2
MSR302
4
MSR304
4
MSR306
4
: Slots for SIC interface cards
: Slots for DSIC interface cards
: Slots for HMIM interface cards
