Figure 59 Pulling the HMIM out of the slot
Figure 60 Installing a filler panel
Replacing a MIM
ARNING!
You can replace a MIM when the router is powered on. However, before replacin
a MIM when the router
is powered on, you must execute the remove hmimslot
slotnumber
command.
To replace a MIM:
1. Completely loosen the captive screws of the HMIM adapter.
2. Gently pull the MIM and the HMIM adapter out of the slot along the slide rails.
