ii
MSR3012 DC
Figure 66 MSR3012 DC front view
(1) Gi
abit Ethernet port (GE1) (2)
Gi
abit Ethernet
port
(GE2)
(3) USB console port (CON)
(4) USB port 1 (5) SFP interface (SFP0) (6) RPS receptacle cover
(7) Power switch (8) DC-input power receptacle
(9) USB port 0
(10) Console port/AUX port
(CON/AUX)
(11) Gigabit Ethernet port (GE0)
Figure 67 MSR3012 DC rear view
(1) Groundin
terminal (2)
SIC slot
(slot 2)
(3) SIC slot (slot 1)
(4) HMIM slot (slot 3)
MSR3024 AC
Figure 68 MSR3024 AC front view
(1) CF card cover (2) USB port 0 (3) USB port 1
2
1
3 4
5 6
7
8
9
10
11
