HP MSR4080 Configuration Guide

203
Device
Interface
IP address
Device
Interface
IP address
R 1 — 10.110.1.2/24 PE 3 GE1/0/3 10.110.6.1/24
R 2 — 10.110.9.2/24 PE 3 Loop1 1.1.1.3/32
R 3 — 10.110.10.2/24 PE 3 Loop2 33.33.33.33/32
R 4 — 10.110.11.2/24 CE a1 GE1/0/1 10.110.7.1/24
P GE1/0/1 192.168.6.2/24 CE a1 GE1/0/2 10.110.2.2/24
P GE1/0/2 192.168.7.2/24 CE a2 GE1/0/1 10.110.9.1/24
P GE1/0/3 192.168.8.2/24 CE a2 GE1/0/2 10.110.4.2/24
P Loop1 2.2.2.2/32 CE a2 GE1/0/3 10.110.12.1/24
PE 1 GE1/0/1 192.168.6.1/24 CE a2 Loop1 22.22.22.22/32
PE 1 GE1/0/2 10.110.1.1/24 CE a3 GE1/0/1 10.110.10.1/24
PE 1 GE1/0/3 10.110.2.1/24 CE a3 GE1/0/2 10.110.5.2/24
PE 1 Loop1 1.1.1.1/32 CE a3 GE1/0/3 10.110.12.2/24
PE 2 GE1/0/1 192.168.7.1/24 CE b1 GE1/0/1 10.110.8.1/24
PE 2 GE1/0/2 10.110.3.1/24 CE b1 GE1/0/2 10.110.3.2/24
PE 2 GE1/0/3 10.110.4.1/24 CE b2 GE1/0/1 10.110.11.1/24
PE 2 Loop1 1.1.1.2/32 CE b2 GE1/0/2 10.110.6.2/24
Configuration procedure
1. Configure PE 1:
# Configure a global router ID, and enable IP multicast routing on the public network.
<PE1> system-view
[PE1] router id 1.1.1.1
[PE1] multicast routing
[PE1-mrib] quit
# Configure an LSR ID, and enable LDP globally.
[PE1] mpls lsr-id 1.1.1.1
[PE1] mpls ldp
[PE1-ldp] quit
# Create a VPN instance named a, and configure an RD and route targets for the VPN instance.
[PE1] ip vpn-instance a
[PE1-vpn-instance-a] route-distinguisher 100:1
[PE1-vpn-instance-a] vpn-target 100:1 export-extcommunity
[PE1-vpn-instance-a] vpn-target 100:1 import-extcommunity
[PE1-vpn-instance-a] quit
# Enable IP multicast routing in VPN instance a.
[PE1] multicast routing vpn-instance a
[PE1-mrib-a] quit
# Create an MD for VPN instance a and enter its view.
[PE1] multicast-domain vpn-instance a
# Create an MD IPv4 address family for VPN instance a and enter its view.
[PE1-md-a] address-family ipv4
