4. Lift the bottom cover o the computer.
Reverse the removal procedures to install the bottom cover.
Replacing the bottom cover
When replacing the bottom cover screws, be sure to install the screws in the order indicated in the following
image.
IMPORTANT: Failure to install the screws in the correct order can result in uneven bottom cover installation.
NOTE: There are ve dierent sizes of rubber screw covers. Be sure that you reinstall them over the correct
screws, as shown in the following images.
The rubber-screw cover sizes are shown in the following image.
Component replacement procedures 27
