HP Officejet Pro X476dn

6. Use a screwdriver to remove the flex cable retainer (callout 1) from the product.
Figure 1-93 Remove the printbar (7 of 12)
1
7. Unthread all three of the printbar cables through the front frame of the product.
Figure 1-94 Remove the printbar (8 of 12)
8. Gently remove the printbar lift lock tool to lower the printbar onto the dolly.
