HP Officejet Pro X476dn

3. Remove the assembly.
Figure 1-82 Remove the web wipe advance assembly (2 of 2)
NOTE: If you are working on the product at a repair center, use a special alignment tool (PN
T-285463) to make sure the sled is aligned correctly. In the field, you will have to align it by sight.
Right cross brace
1. Remove the following components:
●
Rear cover.
●
Left door.
●
Left rear cover.
●
Left front cover.
●
Top cover.
●
Front cover.
