HP Officejet Pro X476dn - Page 9

2. Remove two screws (callout 1) from the front of the product.
Figure 1-83 Remove the right cross brace (1 of 4)
1
3. Remove two screws (callout 1) from the rear of the product.
Figure 1-84 Remove the right cross brace (2 of 4)
1
