System board
NOTE: Liquid metal thermal grease is available as spare part number L65923-001.
Table 6-7 System board descriptions and part numbers
Intel Core i9-9880H processor and 8 GB of discrete graphics memory (GeForce GTX 2080) L57039-xx1
Intel Core i9-9880H processor and 8 GB of discrete graphics memory (GeForce GTX 2070) L57037-xx1
Intel Core i7-9750H processor and 8 GB of discrete graphics memory (GeForce GTX 2080) L57038-xx1
Intel Core i7-9750H processor and 8 GB of discrete graphics memory (GeForce GTX 2070) L57036-xx1
Before removing the system board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Remove the battery and speakers (see Battery and speakers on page 32).
4. Remove the solid-state drive (see Solid-state drive and Optane Memory Module on page 29).
5. Remove the heat sink/fan assembly (see Heat sink/fan assembly on page 35).
6. Remove the second display transfer board (see Second display transfer board on page 38).
7. Remove the power connector board and bracket (see Power connector cable on page 39).
Remove the system board:
1. Disconnect the following cables from the system board:
(1) WLAN antennas
(2) IR camera board cable (ZIF)
(3) Display cable (ZIF)
(4) Power button board cable from power button board
Component replacement procedures 41

HP Omen X Specifications

General

Operating System	Windows 10
Battery	70 Wh
Refresh Rate	144 Hz
Resolution	1920 x 1080
Processor	Intel Core i7-9750H
Graphics	NVIDIA GeForce RTX 2070
